INDUSTRIAL ELECTRIC STEAM BOILERS




Features: easy operation, automatic water level controls, secondary low water cutoff with manual reset, push to reset high limit pressure control, heavy duty heating elements.

  • 0-100 psi pressure capacity
  • Voltages: 208, 220, 240, 380, 480V
  • Control Voltage: 120V  (240V available)
  • Phase: 3ph  (single available on certain models)
Model Boiler HP Steam Output (lbs/hr) kW Dimensions (w x l x h)
PSE-12 1.2 41 12 22 x 29 x 31”
PSE-18 1.8 62 18 22 x 29 x 31”
PSE-24 2.4 83 24 22 x 29 x 31”
PSE-30 3.0 104 30 22 x 29 x 39”
PSE-36 3.6 124 36 22 x 29 x 39”
PSE-48 4.8 166 48 26 x 31 x 45”
PSE-60 6.0 207 60 26 x 31 x 45”
PSE-72 7.2 248 72 26 x 31 x 45”
PSE-108 10.8 373 108 26 x 32 x 55”
COMPAC SYSTEMS Available as a complete package to simplify installations, Pacific Steam Equipment ComPac packaged boiler systems are skid-mounted and pre-piped with a makeup water tank (condensate return) and blowdown tank.
